Product Introduction

"Traffic"0.4~54L/H"Great pressure"20bar

You ChunPVDFPump head andPTFEThe diaphragm has excellent wear resistance and corrosion resistance, and is almost compatible with all chemicals used in the treatment of industrial polluted water and drinking water fields

The service life of the diaphragm exceeds5years

The dosage is unstable and not affected by voltage fluctuations. It can be used100~240It operates stably within the voltage range of volts

It can be installed in a wall-mounted or upright manner-Add installation brackets

The display methods include analog and digital, and the control methods are divided into manualAKSAutomaticAPG/TPGAcceptable4~20maSignal/Pulse signal

AKS/AKL

The analog metering pump has a constant flow rate and can be manually adjusted through the adjustment knob on the front panel. It offers two frequency options0-20%Or ()0-100%It also features a power indicator and comes with an installation bracket along with the pump.AKLEquipped with a low liquid level alarm port.

APG

Analog metering pump, constant flow, manual adjustment, based on external analog signals4-20Milliampere or digital pulse signals can be used to adjust the flow ratio (for example, pulse signals from water meters)

Adjustment knob (percentage and multiplication mode)

Four types of pulse signal inputs can be selected.1:1,4:1,10:1,1:N)

4to20Milliampere signal input

Constant flow

"ThroughDIPThe switch can realize the step adjustment function of the pump

Low liquid level alarm or pump stop

TPG

Digital metering pump, constant flow, manual adjustment, based on external analog signals0/4-20Use milliampere or digital pulse signals to adjust the flow ratio (for example, water meter pulse signals).

Digital metering pumps also have the following additional functions: timing function,ppmDosing, statistics, password and remote control switch.
