Installation method

(1) Select the installation location: The purchased water purifiers are generally installed in the kitchen, living room, or at convenient drinking points for water access. The selection of the installation location shall be based on the original water supply pipeline. At the same time, consider whether it is convenient to drink water Whether the sewage discharge is convenient, whether the electricity supply is convenient, whether the maintenance is convenient, whether it will crack in cold weather, whether it is harmonious and beautiful with the overall space, and also to avoid children touching it.

(2) Accessory selection: The general terminal water supply pipeline is 6 "Divide or 4 They are divided into plastic pipes or metal pipes, while water purifiers generally use them 4 "Divide or 2 In charge.1 Inch pipe6 In charge of4 The branch pipes are general pipe fittings, and there are also interchangeable joints and ball valves. They can be purchased in building materials or hardware stores.2 In charge of right and wrong Standard pipe fittings, and the matching ones are 4 change 2 Connector2 It is divided into direct connection2 "Fenbian Tong,2 It is divided into three channels2 Split nut2 In charge of plugs 2 Graded accessoriesSUS4 Split into three channels(In the middle 2 Split up) ,SUS2 Ball valves, rubber stoppers, rubber nails, etc. Beijing Weimingwang Technology and Trade offers delivery services for all non-standard parts.

(3) Preparation of installation tools: For water purifiers, an impact drill is generally needed to make holes(Drill bit matching 6 "Divide or 8 points)Or make a hole(Selection of hole openersφ11-16mm) So as to fix the direct drinking water machine or water;Raw tape can avoid joints Leakage;Special glue facilitates the connection of plastic joints; Cross-head screwdrivers, flat-head screwdrivers, electric pens, wrenches, scissors, knives, pipe wrenches and other tools are all commonly used installation tools.

(4) Installation process specifications for water purifiers

1, Drill holes or fix the water purifier at the selected position. The holes should be smooth, and the depth and hole spacing should be accurate. The hole circumference must not have cracks, notches or burrs.

2, Connect to the water pipe. First, close the main valve of the tap water, connect the water purifier, and wrap the interface with raw rubber The belt must not leak.

3, Connect the concentrated water discharge outlet. The pure water machine can directly insert the sewage pipe into the sewage pipe. Some space should be left on the port. To prevent sewage from flowing back into the Healthy Home water purifier and to avoid the "siphoning" phenomenon at the sewage outlet;If the water purifier is drained When the sewage pipe is directly connected to the sewage pipe, a ball valve should be installed at the end of the sewage pipe. Opening it from time to time can serve the purpose of sewage discharge;It can also be discharged The pipe is directly connected to the original tap water. The sewage pipe must be properly connected to the sewage outlet of the water purifier to prevent any leakage.

4, Connect the purified water outlet to the purified water. If the flow rate is greater 1000 It can be used directly 4 In charge of and communication with;If the flow rate is less than 1000 It can be used optionally 4 change 2 The joint is connected to the outlet of the purified water through 2 Divided into white PE "Pipe and 2 Separate water connection. "Connect" 2 When dividing the pipe, first cut the pipe end flat, then put on the nut, and finally insert the pipe plug PE Insert the pipe tightly PE The pipe extends beyond the nut 1CM Just insert the connectors left and right and tighten them.

5, Installing water: If you want to install water on the sink, you can use a hole opener to make holes in the stainless steel sink, such as If you want to fix the water on the wall, you can use right-angle hanging pieces to fix the water on the wall. The joint connection method and(4)The same The fixed parts should be tightened and there should be no shaking.

6, Open the main inlet ball valve and debug the water purifier(The debugging steps are detailed in Maintenance and upkeep) Observe the connection Whether the head is leaking or not requires a short period of observation 2 After an hour, you can place a clean dry towel under the water purifier to check if there is any water seepage.
