System features All actions of this system are automatically carried out under the preset program and it has a fully automatic function.

The system structure is compactly arranged, effectively saving space.

The system has low energy consumption and low water production cost.

The system operates reliably, with a closed water supply pipeline and stable effluent quality

Main configuration

Pretreatment system: raw water pump, multi-media filter, activated carbon filter, fully automatic water softener, pipelines, valves

DROReverse osmosis system Primary high-pressure pump, secondary high-pressure pump, reverse osmosis membrane, reverse osmosis membrane housing, membrane frame, control system feed water, solenoid valve, flushing solenoid valve, pressure regulating valve, high-pressure switch, low-pressure switch, precision filter, pipeline, valve.

Storage system: liquid level controller, water tank.

Process Introduction

This process consists of the following parts: pretreatment, two-stage reverse osmosisDRO"

Two-stage reverse osmosis involves connecting two sets of reverse osmosis devices in series, with the product water from the first stage of reverse osmosis serving as the feed water for the second stage. Since the water quality of the first-stage reverse osmosis is far better than that of tap water, the water quality of the second-stage reverse osmosis is better than that of the single-stageROThe water quality produced by the system is better, with lower contents of ions, organic matter and pyrogens.
