Industrial automatic water softening equipment0.5Tons of-100Tons of

Function Introduction

Automatic water softener, industrial water softening equipment; This series of water softeners adopts a fully automatic control device and is a fully automatic ion exchange water softening treatment equipment assembled and formed in China. The manufacturing processes and technologies at home and abroad, the resin tank is made of high-quality fiberglass reinforced plastic anti-corrosion materials. The equipment is of excellent quality, stable and reliable performance, and has achieved fully automatic operation of the water softening equipment. This water softener features a unique self-maintenance function that can restore the entire system's soft water treatment efficiency at regular intervals. Therefore, it has a long-term and stable softening capacity, eliminating the need for frequent replacement of filter cores and filter materials, and significantly reducing operating costs. According to different customer requirements, this water softener can be used in parallel in multiple units to increase the water production.

The total amount of calcium and magnesium ions contained in water quality is called the total hardness of water. During daily life and industrial water use, insoluble precipitates (scale) are prone to form, which will bring many inconveniences to life and production. For example, hard cooling water will cause scale to form in heat exchangers, seriously blocking the water flow channel, greatly reducing the heat exchange effect, and may also cause perforating corrosion and damage equipment. When used as water for boilers, scale will form on the heating surfaces of the boilers, and the thermal conductivity will deteriorate. Textile printing and dyeing can cause spots on fabrics, affecting the appearance and quality of products, etc. The working principle of the softener is to use the exchange effect of groups in the ion exchange resin to change the hardness components in the water body, such asCa2+,Mg2+Plasma displacement removal is carried out to achieve the purpose of softening hard water, reducing the harm caused by scale inside subsequent pipelines and equipment, and extending the service life of the equipment. the JPYSF The hardness of water after treatment by single-stage or multi-stage softeners≤0.02mmol/L . When the softener fails, it needs to be regenerated with sodium chloride, which is extremely convenient to operate.

I.The functions of a water softener

. Soft water washing helps keep tableware and sanitary wares shiny and new

. Hardness ions help prevent water erosion

. Solve the problem of scale-like insulating substances causing trouble to electrical equipment

. Extend water-related household appliances35％The service life

. The electricity consumption of the electric water heater can be saved30％

. Soft water bathing helps you have smooth hair

Ii.The principle of water softening by a water softener

When water containing calcium and magnesium ions passes through a sodium ion exchanger, the calcium and magnesium ions in the water combine with the exchanger, while the sodium ions of the exchanger itself are discharged into the water in equal amounts. This process is called raw water softening. When sodium-type resins fail and transform into calcium or magnesium forms, they are usually restored to their original sodium form by coming into contact with salt solutions. This process is called regeneration, softening, and regeneration cycles to achieve the purpose of treating raw water. Fully automatic regenerative softening treatment, convenient to use.

Iii.Scope of application:In northern regions where water hardness is relatively high and calcium and magnesium ions exceed the standard, well water purification, river water purification, industrial softened water, and make-up water softening for systems such as boilers, condensers, and direct-fired air conditioners, It can also be used for domestic water treatment in hotels, restaurants, office buildings, apartments, etc., as well as for water softening treatment in multiple industries such as food and beverage, brewing, laundry, dyeing and printing, chemical engineering, electronics factories, electroplating factories, laboratories, electronic products, precision automotive products, and medicine. Softening of water for households, bathing, laundry, enterprises and institutions, catering and beauty industries.
