Speaking ofWater treatment equipmentDon't think these have nothing to do with you. As society progresses and people's social standards improve, chemical products are constantly entering our lives. Therefore, our physical health is also affected by them.Water equipmentClosely related to our health.

　　"UtilizeMembrane separation technologyFor cleaning, membrane separation technologies driven by pressure include reverse osmosisRONanofiltrationNFUltrafiltrationUFAnd microporous filtrationMF" The characteristic of membrane separation technology is that it can provide stable and reliable water quality. As the main principle of membrane separation of impurities in water is mechanical sieving, the effluent water quality is very stable, only based on the size of the membrane pore size, and is independent of the raw water quality and operating conditions.

　　"UtilizeActivated carbonThe main characteristics of activated carbon for degradation adsorption are its large specific surface area and pore structure. every1gThe surface area of carbon can reach1000The specific surface area of carbon is an important factor affecting the adsorption performance. The vast majority of it is the surface of the tiny pores inside the particles. As the adsorption effect is the concentration process of dissolved impurities in water on the surface of carbon particles, the specific surface area of carbon is an important factor affecting the adsorption performance. Due to the huge surface area of activated carbon, it shows excellent adsorption performance.

　　Fully automatic water softenerBeijing Yuanlai Company has developed and produced energy-saving fully automatic sodium ion exchange equipment by introducing control technology and components from the United States. This equipment can automate the entire process including softening, backwashing, salt drawing, slow washing, fast washing and water filling in the salt tank.

I. Basic Principles

　　The water softener uses strong acidic cation resin to replace calcium and magnesium ions in the raw water. The water flowing out of this equipment is softened water with extremely low hardness. Its chemical reaction is:2RNa+Ca2+(Mg2)=R2Ca(Mg)+2Na+. The resin is regenerated when it has adsorbed a certain amount of calcium and magnesium ions-Soak the resin in saturated brine to displace calcium, magnesium ions and other hardness substances in the resin, restore the resin's softening exchange capacity, and discharge the waste liquid. Its chemical reaction is:R2Ga=2RNa+Ca2+ . The entire regeneration process includes: backwashing-Loosen the resin layer and wash slowly by absorbing salt-An exchange reaction occurs, followed by rinsing (forward washing)-Wash away the calcium and magnesium ions exchanged during the chemical reaction and then fill with water-For the next generation.

Ii. Main technical Indicators of Water Softening Equipment

　　1. Inlet water pressure0.2~0.5Mpa

　　2. Raw water hardness<12mmol>8 mmol/L

　　3. Effluent hardness<0.03mmol/L (Meet the "National Water Quality Standard for Low-Pressure Boilers"

　　4. The salt content of raw water<1000mg/LTurbidity<5

　　5. Power supply~220V,50HZ

　　6. Salt consumption<100g/Gram equivalent(It is related to the hardness of the raw water);

　　7. Water consumption<2%; Electricity consumption<40W

Iii. Equipment Features of Yuanlai Water Softener

　　1. High-performance ion exchange resins are selected, featuring large working exchange capacity, low energy consumption and long service life.

　　2. The control section is fully equipped with imported controllers to ensure the continuous operation of the equipment.

　　3. The fully automatic control system ensures stable water output and convenient and quick operation.

　　4. The structure is reasonable and the installation and operation are convenient.

　　5. The corresponding equipment can be personalized designed according to the actual usage requirements.

　　6. Wide application: It can be used in steam boilers, hot water boilers, air conditioners, steam condensers, heat exchangers and other make-up water equipment. It can also be used for the treatment of domestic water in hotels, restaurants, office buildings, apartments, etc., as well as for soft water treatment in industries such as beverages, brewing, chemicals, and pharmaceuticals.

Iv. Time Control and Flow Control

　　Fully automatic water softeners are classified into two types based on different regeneration control methods: time control and flow control.

1,Time control

　　Time control refers to the automatic initiation of the regeneration process when the equipment operation reaches the set regeneration time. This type of system sets the regeneration time based on the actual water consumption and the exchange capacity of the equipment. Users can select the regeneration process during periods with lower water consumption or start it manually at any time as needed.

　　The advantages of time control1The price is low.2Easy to operate

　　Disadvantages of time control:1Generally every24It can only regenerate once every hour.2The time point for regeneration cannot be precisely determined based on the actual usage conditions

　　Applicable occasions: Time-type control is generally applied in situations where the hardness is relatively low<4mmol/LThe water consumption is stable (the fluctuation in water usage does not exceed.15%In cases where the effluent quality requirements are not high and the water consumption is relatively small.

2,Flow control

　　Flow control is to set the operation endpoint based on the exchange capacity (total water production) of the equipment. When the equipment is in operation, a dedicated flowmeter is used to count the volume of water flowing out. When the total water output reaches the set water volume, the controller automatically starts the regeneration process. Before setting, the total water production for each cycle should be calculated based on the total resin filling volume and the hardness of the raw water, and then set according to this value.960The water production volume of the series is automatically calculated by the controller. When the set water volume is reached, regeneration can be carried out immediately as needed or wait for a certain set time before regeneration.

　　The main features of flow control:

　　1Regeneration is controlled by flow rate, with high precision. Consumption can be reduced, and the operation is economical and reliable.

　　2It features a backup battery and built-in memory function, eliminating the need to reset the values during power outages.

　　3The time for each step of the regeneration process can be set as needed. Manual re-operation makes it easy to start a new running cycle.

　　4Digital Settings and displays can show information such as instantaneous flow rate, remaining water volume in a cycle, and remaining time during regeneration, making it clear at a glance.

　　Applicable scenarios: This system is more adaptable to fluctuations in water consumption and water quality, and its control is more accurate and stable. It is more suitable for water usage scenarios with higher requirements such as fuel oil and gas-fired boilers and air conditioners.
