The mineral water equipment produced by Beijing Yuanlai Water Treatment Company,Complete set of mineral water equipment,High-end mineral water equipment is suitable for good mineral water regions in our country, such as the production of high-end mineral water equipment, Inner Mongolia mineral water equipment, Xinjiang mineral water equipment, Beijing mineral water equipment, and volcanic mineral water equipment,Bottled mineral water equipment, etc.

　　This complete set of mineral water equipment includes a mineral water treatment section (generally using ultrafiltration equipment)/Water treatment equipment, mineral water section, mineral water pipeline cleaning sectionCIP(), bottle blowing section, bottle loading section, bottle feeding section, rinsing-irrigation-Sealing three-in-one part, bottle cap part, bottle cap conveying part, light inspection, sleeve labeling/Labeling, laser marking/Laser engravingPVCShrinking package/Carton packing/Paper wrapping, stacking, and leaving the factory.

　　At present, there is a more advanced complete set of mineral water equipment technology, the blow molding machine and the three-in-one filling machine integrated blow, fill and screw machine. It has the characteristics of smaller floor space, lower equipment scrap rate and convenient maintenance, and is mainly applied in15000bottle/"Hour~42000Bottles and large barrels of water/Hourly filling is one of the more advanced filling technologies in China and is widely adopted by large water plants.

　　1.Mineral water purification equipment section

　　Adopting high-quality Grundfos special pumps or high-quality domestic Nanfang pumps, the main functions are: constant system water supply pressure and stable water supply volume

　　2.The principle of mineral water equipment

　　Mineral water equipment, mineral water filling production lines, and bottled water equipment use filters with multiple filtration layers. The main purpose is to remove heavy metals such as manganese and iron, sediment, rust, colloidal substances, and suspended matter from the raw water20μmFor the above-mentioned substances, the system can perform a series of operations such as backwashing and forward washing.

　　Main functions: Ensure the water production capacity of mineral water equipment, mineral water filling production lines, and bottled water equipment, and extend the service life of the equipment.

　　3.Activated carbon filter

　　Mineral water equipment, mineral water filling production lines, and bottled water equipment all adopt fruit shell activated carbon filters. Activated carbon can not only adsorb electrolyte ions but also perform ion exchange adsorption. Adsorption by activated carbon can also increase the oxygen consumption of potassium permanganateCOD"By"15mg/L(02"Drop"2-7mg/L(02)In addition, due to the adsorption effect, the concentration of adsorbed and replicated substances on the surface increases, thus also playing a catalytic role, removing pigments, odors, a large amount of biochemical organic matter in water, reducing the residual halogen value and pollutants in water, and eliminating trihalides in water.THMAnd other pollutants. The system can perform a series of operations such as backwashing and forward washing. Meanwhile, the equipment is equipped with a self-maintenance system and has very low operating costs.

　　Main functions: Ensure the water quality produced by mineral water equipment, mineral water filling production lines, and bottled water equipment, and extend the service life of the equipment

　　4.Precision filter

　　Precision filters are used to retain a small amount of mechanical impurities that leak through mineral water equipment, mineral water filling production lines, and the pretreatment systems of bottled water equipment. The filter cylinder is made of engineering plastics orSUS304Material; Interior decorationPPFFilter element. Polypropylene filter elements are a type of deep filtration component with high efficiency and low resistance. It is suitable for applications with low suspended impurities (turbidity less than.2-5The water is further purified. Polypropylene filter elements are formed by winding polypropylene fibers around injection-molded polypropylene porous tubes in a certain pattern.

　　Main function: Ensure that the water particle size entering the mineral water equipment, mineral water filling production line, and bottled water equipment membrane is less than0.1μm

　　5.Introduction to Ultrafiltration Purification Membrane Modules

　　The ultrafiltration membrane modules of mineral water equipment, mineral water filling production lines, and bottled water equipment are membrane separation processes driven by pressure. Through the micro-pore screening on the membrane surface, the diameter can be reduced to0.002-0.1μmThe retention of particles and impurities between them can effectively remove colloids, silicon, proteins, microorganisms and macromolecular organic substances from water. When a liquid mixture flows over the membrane surface under a certain pressure, the solvent and small molecules pass through the membrane, while large molecules are retained, thus achieving the purpose of separation and purification between large and small molecules. It can be widely applied to the separation, concentration and purification of substances. The ultrafiltration process involves no phase transformation, does not require heating, can be operated at room temperature, saves energy, and is particularly suitable for the separation of heat-sensitive substances. The ultrafiltration process is simple, requires few supporting devices, is easy to operate and run, and has low maintenance costs. Ultrafiltration membranes are resistant to chemical erosion.PHIt has a wide range of applications. The ultrafiltration device has a large membrane area per unit volume, low investment cost and is easy to clean.

　　Hollow fiber ultrafiltration membranes are one of the most mature forms of ultrafiltration technology in mineral water equipment, mineral water filling production lines, and bottled water equipment. The outer diameter of hollow fibers?0.5-2.0mmInner diameter?0.3-1.4mmThe walls of hollow fiber tubes are covered with micro-pores, and the pore diameters are expressed in terms of the molecular weight of the substances that can be retained, which can reach several thousand or even several hundred thousand. The raw water flows under pressure on the outside or inside the hollow fiber cavity, respectively forming the external pressure type and the internal pressure type. Ultrafiltration is a dynamic filtration process. The retained substances can be discharged along with the concentration without clogging the membrane surface, and it can operate continuously for a long time.

　　6.The characteristics of ultrafiltration devices

　　The ultrafiltration devices of mineral water equipment, mineral water filling production lines and bottled water equipment adopt vertical cross-flow filtration methods, which can effectively clean or perform backwashing selection. Therefore, it has performance different from other purification and separation devices: High precision: Thoroughly filter out substances such as rust, colloids, and large-molecule organic matter in water while retaining them The trace elements beneficial to human health, the main indicators of the purified water such as microorganisms and turbidity are superior to the hygiene standards of bottled drinking water. Long service life: Due to the vertical cross-filtration principle adopted by the ultrafiltration machine, it can be automatically cleaned and is not prone to clogging. Therefore, under normal usage conditions, the service life of the filter core is that of ordinary water purifiers30-50Multiple, high flow rate: It can simultaneously meet the needs of direct drinking, beauty care, bathing, consumption, and hygiene cleaning. Low cost: Due to the large flow rate, long service life and maintenance-free nature of the ultrafiltration machine, the cost of treating each ton of purified water is only about one yuan, which is much lower than that of other purification devices.

　　7.Process flow diagrams for mineral water equipment, mineral water filling production lines, barrel water equipment, and bottled water equipment
