During the operation of water softening equipment, it is often encountered that the resin leaks, that is, the water softening resin flows into the sewer or water tank, resulting in the waste of resin and substandard softened water output. So, what causes this?

Now, let's take a look together at the reasons for resin leakage in water softening equipment and the solutions!

The common reasons for resin leakage during the water production process of the water softener are: pipe rupture, detachment or rupture of the lower water distributor, and a large amount of resin entering the water softener tank. It is easy to detect by disassembling the resin tank and pulling out the pipe for inspection. If there is any damage, replace the pipe or water distributor.

All along, the engineers of Beijing Yuanlai Water Treatment Technology have been relying on their rich on-site experience and technical expertise to carefully analyze and identify problems, and then meticulously solve them, providing every service to customers!

1During the regeneration process, the pressure inside the bed should not be too high. There are two purposes for this: one is to prevent the brine from not being able to enter due to high pressure inside the bed. Second, it is to prevent the salt water being regenerated from leaking into the running bed due to the salt water inlet door not being tight, which may cause the hardness of the effluent from the running bed orCl-The content increases.

2Regular backwashing of the salt filter is necessary as industrial salt contains a certain amount of sand. If not removed, it may enter the softening bed with the salt water and accumulate in the resin layer, affecting the regeneration or operation effect of the softening bed. To ensure the operational effect of the salt filter, it should be backwashed regularly. Each can be considered25-30dBackwash once. The backwashing of the salt filter can be carried out in accordance with the operation of a general filter.

3Do not interrupt the regeneration process, as it may cause air to enter the resin layer, thereby affecting the regeneration effect.

4During the regeneration process, it is necessary to always keep the water flowing through the monitoring tube, indicating that there is a certain thickness of water layer on the resin layer. This has two benefits: First, it prevents air from entering. Second, it can prevent the salt water from directly impacting the resin surface, causing the resin layer surface to be uneven and resulting in flow deviation.

5To enhance the regeneration effect, a two-step regeneration method can be adopted: First, increase the amount of salt used for regeneration1/3Prepare it to a thinner concentration(1%-2%). And then add the rest2/3Prepare it to a relatively concentrated concentration(8%-10%)Regeneration can achieve better results.

Ii. Tips for Installing Water softening Equipment, as follows:

1There is no need to specially build an installation foundation; a level ground is sufficient. There is a certain gap from the wall, and it can be arranged along the corner according to the actual situation.

2The inlet and outlet water pipes are connected by standard flanges or threads. They need to be fixed and supported well and must not rely on the valve body for support to prevent stress.

3A water pressure gauge should be installed on the water inlet pipe. When the equipment is in operation and flushing water is discharged, floor drains or drainage ditches should be set up nearby. The sewage pipe should not be longer than6Do not install a stop valve, the outlet should not be higher than the valve body, and the terminal should be open[To avoid siphoning]The fewer elbows, the better.

4If the inlet water pressure is lower than0.2mpaA pipeline pump must be installed.

5Before use, the pipeline must be flushed first to prevent impurities from blocking the valve body and contaminating the resin.

6Salt water pipe: The salt water tank should be as close as possible to the softening tank, and the shorter the salt water pipe, the better.

7Power distribution sockets installed on the wall near the equipment should be equipped with fuses[Generally, do not install switches]Good grounding is required.
