Cleaning RO reverse osmosis equipment - All-stainless steel two-stage reverse osmosis pure water equipment

Released Date: Apr 10,2019 Article Source: Yuanlai Water Treatment

We always adhere to the principle of putting customers first and serving them wholeheartedly

"Clean"ROReverse osmosis equipment-All-stainless steel double-stage reverse osmosis pure water equipment-Car washing reverse osmosis equipment

Pure water equipment device

I. Product Description:

The deionized pure water device is composed of reverse osmosis, electrodialyzer, ion exchangerEDIA water treatment device that removes cations and anions from water by other methods.

Ii. Deionized pure Water Equipment and Device process

1"Pre-treatment-Reverse osmosis-Water tank-Yang bed-"Yin bed"-Mixed bed-Purified water tank-Pure water pump-Ultraviolet device-Refined mixed bed-Precision filter-Water usage object

2"Pre-treatment-First-stage reverse osmosis-Dosing machine(PHRegulation)-Middle water tank-Stage reverse osmosis-Purified water tank-Pure water pump-Ultraviolet device-0.2or0.5μmPrecision filter-Water usage object

3"Pre-treatment-Reverse osmosis-Middle water tank-Water pump-EDIDevice-Purified water tank-Pure water pump-Ultraviolet device-0.2or0.5μmPrecision filter-Water usage object

4"Pre-treatment-Reverse osmosis-Middle water tank-Water pump-EDIDevice-Purified water tank-Pure water pump-Ultraviolet device-Refined mixed bed-0.2or0.5μmPrecision filter-To meet the needs of users and achieve water quality that meets the standards, and to minimize pollution at all levels as much as possible, in the process design, water that meets the national tap water standards is taken as the source water, and then a pretreatment system such as medium filters, activated carbon filters, and precision filters is set up.ROReverse osmosis main unit system, ion exchange mixed bed system, etc.

5Composite bed: Two exchangers are used. Anion and cation exchange resins are loaded into their respective exchangers as per the design requirements. The raw water is first exchanged with cation exchangers, and the cations in the water are as followsCa2+,Mg2+,K+,Na+Those that are adsorbed by the exchanger and can be exchanged on the exchangerH+It is displaced into water and forms corresponding inorganic acids with anions in water;The effluent then passes through an anion exchanger, and the anions in the water are as followsSO42-,CL-,HCO3-The exchangeable ions on the exchanger that are adsorbed by the exchangerOH-Displaced in water and with the waterH+Combine intoH2O.

Iii. System Features

Imported silent pumps are selected. During system operation, there is no vibration, no noise and no electromagnetic radiation, which has no impact on the working environment.

Original reverse osmosis membranes imported from the United States are selected, featuring stable performance, high desalination rate and long service life.

It is made of original imported Romenhaus resin from the United States, Polite resin, Beijing Yuanlai resin, Shanghai Zhen Guang resin and exchange resin(super)The purification column has a large exchange capacity and high effluent quality.

The all-metal chassis is selected and electrostatically sprayed, which can effectively prevent rust caused by water vapor.

The waterway and circuit are isolated to avoid the influence of a humid environment on the circuit.

Iv. Product Parameters

Inlet water source Urban tap water　

Water temperature5-40℃　

Water pressure1-5Kg TDS≤300ppm

Grade 3 water conductivity2-10μs/cm,

Two-stageRO(Electrical conductivity≤5μs/cm)

First-level water conductivity≤0.1μs/cm,

Resistivity10-15MΩ·cm

The effluent quality meets the standards for national laboratory water
